CleanSound
A wide range of sound absorbing and at the same time cleanable ceilings
CleanSound
Acoustical Vinyl Laminate Ceilings
We recommend this vinyl laminate to customers who require high reverberation control, mostly in offices and public spaces. These tiles can also be produced without PVC coating, with a matte white water-based coating. It is the most cost-effective ceiling and the preferred choice of investors because it produces optimum results in relation to its cost.
Título de diapositiva
Escriba su subtítulo aquíBotón
Título de diapositiva
Escriba su subtítulo aquíBotón
Título de diapositiva
Escriba su subtítulo aquíBotón
CleanSound Ceiling
Ficha Técnica:
Borde: Cuadrado - Tipo A
Espesor: 8,00; 9,50 ;12,50mm (±0,5mm)
Peso medio: 5,80; 6,55; 9,10 kg/m2
Unidades / Caja: 8 placas (595x595mm)
= 2,88 m2
6 placas (1195x595mm)
= 4,32 m2
Conductividad térmica: 0,25 W/m K
(Norma UNE EN 12524)
Reacción al fuego: A2 s1 d0 (Certificación
Nº EEA-1800-0071)
Resistencia al fuego: 30 min.
Película de revestimiento: Policloruro de vinilo COLOR BLANCO 80 g/m2
Uso indicado: Techos removibles en salas de reuniones, salones de actos, pasillos o corredores, oficinas y locales, donde se requiera absorción acústica.
Resultados de certificación:
Espesor del tablero probado: 12,50 mm
Densidad aproximada: 730 kg/m3
Clasificación de la placa base: NO COMBUSTIBLE (A2 s1 d0)
Superficie perforada: 16,6%
DATA SHEET
Edge Square - Type A
Thickness 8,00; 9,50; 12,50 mm (±0,5mm)
Average weight 5,80; 6,55; 9,10 kg/m2
Units / Box 8 panels (595 x 595mm)
6 panels (1195 x 595 mm)
Thermal conductivity 0.25 W/m K (Standard UNE EN 12524)
Reaction to fire A2 s1 d0 (Certification No. EEA-1800-0071)
Fire resistance 30 min.
Coating film Polyvinyl Chloride COLOR WHITE
80 g/m2
Indicated use Removable ceilings in meeting rooms, assembly halls, hallways/corridors, offices and premises where acoustic absorption is required.
Certification results
Board thickness tested 12,50 mm
Approximate density 730 kg/m3
Backerboard classification NON-COMBUSTIBLE (A2 s1 d0)
Perforated surface area 16,6%
-
Product Information:
A special ceiling for offices and public spaces, where it provides a high level of acoustic absorption, while maintaining high mechanical resistance and its unalterable white color.
Its perforations and the fibers behind them provide greater reverberation control. Its high acoustic performance, fire resistance, moisture resistance and minimal impact on the environment are features appreciated by architects, designers and all professionals involved in the suspended ceiling business.
The price-quality ratio of this laminate ceiling is high. That makes it an option for many offices and public spaces.
Benefits of this type of ceiling
High acoustical performance
Easy to clean
High light reflection
Resistance to humidity
Recyclable
Durability and resistance
High fire resistance
CleanSound
A wide range of sound absorbing and at the same time cleanable ceilings
CleanSound
Acoustical Vinyl Laminate Ceilings
We recommend this vinyl laminate to customers who require high reverberation control, mostly in offices and public spaces. These tiles can also be produced without PVC coating, with a matte white water-based coating. It is the most cost-effective ceiling and the preferred choice of investors because it produces optimum results in relation to its cost.
Título de diapositiva
Escriba su subtítulo aquíBotón-
Título de diapositiva
Escriba su subtítulo aquíBotón -
Título de diapositiva
Escriba su subtítulo aquíBotón
CleanSound Ceiling
Data Sheet
Edge: Square - Type A
Thickness: 8,00; 9,50; 12,50 mm (±0,5mm)
Average weight: 5,80; 6,55; 9,10 kg/m2
Units / Box: 8 panels (595 x 595mm)
6 panels (1195 x 595 mm)
Thermal conductivity: 0.25 W/m K (Standard UNE EN 12524)
Reaction to fire: A2 s1 d0 (Certification No. EEA-1800-0071)
Fire resistance: 30 min.
Coating film: Polyvinyl Chloride COLOR WHITE 80 g/m2
Indicated use: Removable ceilings in meeting rooms, assembly halls, hallways/ corridors, offices and premises where acoustic absorption is required.
Certification results:
Board thickness tested: 12,50 mm
Approximate density: 730 kg/m3
Backerboard classification: NON-COMBUSTIBLE (A2 s1 d0)
Perforated surface area: 16,6%
Ficha Técnica:
Borde: Cuadrado - Tipo A
Espesor: 8,00; 9,50; 12,50 mm (±0,5mm)
Peso medio: 5,80; 6,55; 9,10 kg/m2
Unidades / Caja: 8 placas (595 x 595mm)
6 placas (1195 x 595 mm)
Conductividad térmica: 0,25 W/m K (Norma UNE EN 12524)
Reacción al fuego: A2 s1 d0 (Certificación Nº EEA-1800-0071)
Resistencia al fuego: 30 min.
Película de revestimiento: Policloruro de vinilo
COLOR BLANCO 80 g/m2
Uso indicado: Techos removibles en salas de reuniones, salones de actos, pasillos/ corredores, oficinas y locales donde se requiera absorción acústica.
Resultados de certificación:
Espesor del tablero probado: 12,50 mm
Densidad aproximada: 730 kg/m3
Clasificación de la placa base: NO COMBUSTIBLE (A2 s1 d0)
Superficie perforada: 16,6%
-
Product Information:
A special ceiling for offices and public spaces, where it provides a high level of acoustic absorption, while maintaining high mechanical resistance and its unalterable white color.
Its perforations and the fibers behind them provide greater reverberation control. Its high acoustic performance, fire resistance, moisture resistance and minimal impact on the environment are features appreciated by architects, designers and all professionals involved in the suspended ceiling business.
The price-quality ratio of this laminate ceiling is high. That makes it an option for many offices and public spaces.
Benefits of this type of ceiling
High acoustical performance
Easy to clean
High light reflection
Resistance to humidity
Recyclable
Durability and resistance
High fire resistance
